TECH SPECS
Size | Luff | Boom | MAST | IMCS | BASE | BATTENS | TOP | CAMS | DIAMETER | WEIGHT |
---|---|---|---|---|---|---|---|---|---|---|
3,0 | 320 | 137 | 340 | 14 | 0 | 4 | Adj | 0 | RDM | 2.63 |
3.3 | 334 | 140 | 340 | 14 | 0 | 4 | Adj | 0 | RDM | 2.71 |
3.7 | 351 | 145 | 340 | 14 | 12 | 4 | Adj | 0 | RDM | 2.83 |
4.0 | 366 | 150 | 370 | 17 | 0 | 4 | Adj | 0 | RDM | 2.9 |
4.2 | 377 | 155 | 370 | 17 | 8 | 4 | Fixed | 0 | RDM | 2.9 |
4.5 | 389 | 158 | 370 | 17 | 20 | 4 | Fixed | 0 | RDM | 3 |
4.7 | 398 | 162 | 370 | 17 | 28 | 4 | Fixed | 0 | RDM | 3.11 |
5.0 | 409 | 167 | 400 | 19 | 10 | 4 | Fixed | 0 | RDM | 3.21 |
5.4 | 419 | 172 | 400 | 19 | 20 | 4 | Fixed | 0 | RDM | 3.25 |
5.8 | 432 | 179 | 430 | 21 | 2 | 4 | Fixed | 0 | RDM | 3.44 |
FEATURES :
1 – CONTINUOUS LUFF PANELS
The Manic features a panel layout with 2 continuous luff panels, ensuring a stronger and more efficient load distribution. This design not only enhances the sail’s durability but also optimizes its performance.
2 – INTEGRATED BATTEN TECHNOLOGY
All the battens above the boom feature our Integrated Batten Technology for maximum symmetry and stability. This design choice optimizes the sail’s performance across a wide range of conditions.
3 – 4-BATTEN SETUP
Across all sizes, the Manic sail features a 4-batten skeleton, providing consistent performance and handling characteristics as well as providing the perfect mix of stability and lightness.
4 – LIGHTWEIGHT CONSTRUCTION
The Manic’s construction is optimized for lightness without compromising on strength. The top half of the sails is constructed using exclusive 2-Ply material, with 1.75 mil in the center and 2.5 mil at the leech. This ensures both durability and reduced weight.
5 – CARBON RADIAL TAPES
The sail’s profile is stabilized by carbon radial tapes spreading from the clew, ensuring that the sail maintains its shape and responsiveness even in demanding conditions.
7 – ENHANCED STABILITY
The sail’s outline features enhanced stability and reduced backhand pressure. These improvements allow for a more comfortable and controlled riding experience, especially in challenging conditions.
8 – ONE-PIECE MAST SLEEVE
The one-piece mast sleeve makes the Manic lighter and improves stretch characteristics.
9 – COMPACT SAIL WINDOW
A more compact sail window provides great visibility, while eliminating unnecessary seams and interferences with other materials.
